Enregistreur UNV NVR 32CH 4 SATA interface NVR304-32S-P16

Name: Enregistreur UNV NVR 32CH 4 SATA interface NVR304-32S-P16
Brand: UNIVIEW
SKU: NVR304-32S-P16
Availability: InStock

Enregistreur NVR pour caméra IP Gamme facile Prise en charge des formats vidéo, Ultra265/H.265/H.264 Entrée 16/32 canaux Plug & Play avec 16 interfaces réseau PoE indépendantes Prend en charge les caméras grand public de conformité ONVIF (profil S, profil G, profil T) et les protocoles RTSP Prise en charge de la sortie simultanée HDMI et VGA Enregistrement avec une résolution allant jusqu’à 8 mégapixels 4 disques durs SATA, jusqu’à 10 To pour chaque disque dur Technologie ANR pour améliorer la fiabilité du stockage lorsque le réseau est déconnecté

Brand:

UGS : NVR304-32S-P16 Catégories : Enregistreur, Enregistreur NVR, RESEAUX ET SECURITE

1.818,000 DT

Réserver sans intérêt jusqu’à 6 mois

Description

Model		NVR304-32S-P16
Video/Audio Input
IP Video Input		32-ch
Two-way Audio Input	1-ch, RCA
Network
Incoming Bandwidth	160Mbps
Outgoing Bandwidth	64Mbps
Remote Users	128
Protocols	TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP
Browser	IE(IE10/11) for Windows Firefox (version 52.0 and above) for Windows Chrome(version 45 and above) for Windows Edge(version 79 and above) for Windows
Video/Audio Output
HDMI/VGA Output	HDMI: 4K (3840×2160@30), 1920X1080@60, 1920X1080@50, 1600X1200@60, 1280X1024@60, 1280X720@60, 1024X768@60 VGA: 1920X1080@60, 1920X1080@50, 1280X1024@60, 1280X720@60, 1024X768@60
Recording Resolution	8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Audio Output	1-ch, RCA
Audio Compression	G.711A, G.711U
Synchronous Playback	16-ch
Liveview display		1/4/6/8/9/16/25/36
Corridor Mode Screen		3/4/5/7/9/10/12/16/32
Decoding
Decoding format	Ultra 265/H.265/H.264
Live view/Playback	8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Capability		2 x 4K@30, 4x 4MP@30, 5 x 3MP@30, 8 x 1080P@30, 16 x 720P@30, 32 x D1@30
Hard Disk
SATA	4 SATA interfaces
Capacity	Up to 10TB for each disk
Smart
VCA Detection by Camera	Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Ultra Motion Detection(UMD)
VCA Search	Behavior Search
People counting	People Flow Counting, Crowd Density Monitoring
Smart Intrusion Prevention (SIP), UMD by Camera	Total 8-ch
General Alarm
General Alarm	Motion, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection
Alert Alarm	IP Conflict, Network Disconnected, Disk Offline , Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal
External Interface
Network Interface	1 RJ-45 10M/100M/1000M self-adaptive Ethernet Interface
USB Interface	Front panel: 1 x USB2.0, Rear panel: 1 x USB3.0
RS232	NA
RS485	1
Alarm In	16-ch
Alarm Out	4-ch
